Shanghai Hot selling NE chain bucket elevator

Date:2012-12-08 06:12:57

Detailed Description of NE chain bucket elevator:

NE chain bucket elevator is a new type of bucket elevator which is used for the flowing feed method, Gravity induced discharging the material. And use the Intensive large capacity hopper conveyor.

---Transport capacity can be 15~800 m3/h
---The largest particle size can be 195m




Advantages and features of NE chain bucket elevator:

1.Elevate a large space. This type of equipment have little requirement on size, type and feature. Can elevate powder, granular and lump materials, also for the milled material. Elevate tempreture  below 250 Degrees Celsius materials.

2.Large transmission capacity. Elevate the capacity up to 15-800 cubic meters / hour.

3.Low energy consumption. This machine used for the flowing feed method, Gravity induced discharging the material. And use the Intensive large capacity hopper conveyor. Low chain speed, but big transmission capacity, nearly no material flow back, so small drive power, Theoretical calculation Shaft power is 25%-45% for the Cycle chain elevator

Technology Data of NE chain bucket elevator:

Model Capacity  (m3/h) Max.   particle  size  (mm) Material  bulk  density  (t/m3) Max.   lifting  height                        (m) Motor  Power  (kw) NE15 10-15 40 0.6-2.0 35 1.5-4 NE30 18.5-31 55 0.6-2.0 50 1.5-11 NE50 35-60 60 0.6-2.0 45 1.5-18.5 NE100 75-110 70 0.6-2.0 45 5.5-30 NE150 112-165 90 0.6-2.0 45 5.5-45 NE200 170-220 100 0.6-1.8 40 7.5-55 NE30 230-340 125 0.6-1.8 40 11-75 NE400 340-450 130 0.6-1.8 30 18.5-90 NE500 450-550 140 0.6-1.8 30 30-110 NE600 550-660 150 0.6-1.8 30 37-132 NE800 680-830 165 0.6-1.8 30 37-160


Note: This specification is just referencing, any changes are subject to the products.
